15m (50ft) LC/UPC to LC/UPC OM3 Multimode Fiber Optic Cable, Full Duplex 50/125µm Zipcord Fiber, 100G Networks, LOMMF/VCSEL, <0.3dB Low Insertion Loss, LSZH Fiber Patch Cord

Availability:

2 in stock


  • OM3 FIBER CABLE: OM3 Laser-Optimized Multimode Fiber Cable delivers up to 100 Gbps Ethernet; Full-duplex zip-cord with color-coded TX/RX connectors for cabling servers and Storage Area Networks (SANs)
  • QUALITY CONSTRUCTION: 50/125µm fiber core/cladding is immune to EMI; Protective Aramid fiber sheath for improved tensile strength and crush resistance; LC/LC connectors with UPC polished ceramic ferrules for insertion loss below 0.3dB
  • RATINGS AND RELIABILITY: Individually tested for signal integrity; LSZH jacket emits low-smoke and fumes in case of fire; TIA/EIA compliant fiber core; Attenuation value under 2.3dB/km meets or exceeds industry standards
  • WIDE COMPATIBILITY: OM3 LC/LC multimode cable supports 1/10/40/100 Gbps networks; Backward compatible with OM3; For high-density network applications such as SANs, data servers, fiber switches, SFP+, QSFP+, and QSFP28 transceivers
  • SPECS: 15m (49ft); Color: Aqua (OM3); LC/LC UPC; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: ≥2000MHz·km at 850nm; Cable OD: 2.9mm; Bend Radius: Static 1.2in (3cm), Dynamic 2.4in (6cm); Backed for Life

$45.88

2 in stock

Compare
This OM3 LC to LC Multimode Duplex Fiber Optic Patch cable features 50/125 micron fiber and supports high-bandwidth data transmission over a 10 Gigabit Ethernet connection.

Built for Performance

With laser-optimized multimode fiber (LOMMF), the patch cable is ideal for connecting 850 nm Vertical Cavity Surface Emitting Laser (VCSEL) and LED sources. The high-speed connectivity on the aqua fiber-optic cable provides a high-bandwidth solution for your data centers or high-density applications.

Reliable Connection

Each OM3 fiber cable is individually tested and certified to be within acceptable optical insertion loss limits for guaranteed compatibility and 100% reliability.

High-Quality Construction

Housed in a LSZH (Low-Smoke, Zero-Halogen) flame retardant jacket, this fiber-optic cable ensures minimal smoke, toxicity and corrosion when exposed to high sources of heat, or in the event of a fire.  It’s the best choice for a wide range of environments, including industrial settings, central offices and schools, as well as residential settings where building codes are a consideration.

A50FBLCLC15 is backed by a StarTech.com lifetime warranty and free lifetime technical support.


Applications

  • Use in 10 Gigabit high-speed network environments
  • High-speed connectivity for high-density applications
SKU: A50FBLCLC15 Categories: , Tag:

Specifications

Warranty Information
Warranty
Lifetime

Connector(s)
Connector A
1 – Fiber Optic LC Duplex
Connector B
1 – Fiber Optic LC Duplex

Environmental
Humidity
0~90% RH
Operating Temperature
-20°C to 60°C (-4°F to 140°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)

Hardware
Fire Rating
LSZH Rated (Low Smoke Zero Halogen)
Fiber Size
50/125

Packaging Information
Package Height
1.3 in [32.0 mm]
Package Length
8.7 in [22.0 cm]
Shipping (Package) Weight
7.3 oz [206.0 g]
Package Width
7.9 in [20.0 cm]
Package Quantity
1

Performance
Maximum Data Transfer Rate
100Gbps
Cable Rating
1Gbps / 10Gbps / 40Gbps / 100Gbps
Fiber Classification
OM3
Type
Multi Mode
Wavelength
850nm

Physical Characteristics
Product Height
0.0 in [0.0 cm]
Product Length
49.2 ft [15.0 m]
Weight of Product
6.9 oz [195.0 g]
Product Width
0.0 in [0.0 cm]
Color
Aqua
Cable Length
49.2 ft [15 m]

What’s in the Box
Included in Package
1 – 15 m Fiber Patch Cable
